Mondraker Dune 2019



Mondraker Dune 2019
The Mondraker Dune is back again for 2019. Now with more travel, a revised frame with a brand new rear triangle, larger pivot axles and bearings giving the bike increased strength, durability and performance. Utilising high-end components from market leading brands such as SRAM, Rockshox and Fox, the Dune is now classed as a super-enduro bike.
Updated for 2019; Stealth alloy frame with brand new rear triangle
Removeable shock fender to protect the rear shock from debris etc
Maxxis Minion DHF & DHR tyres provide awesome traction
Internally routed OnOff Pija dropper post
The updated frame also has a new monoblock upperlink and a removeable rear shock fender for extra protection. The Dune runs the highly impressive Rockshox Yari fork up front with 170mm of trail devouring travel. A Fox DPX2 LV EVOL trunnion mounted shock takes care of the rear suspension with 3 compression settings and 170mm of travel.
The SRAM NX 11 speed drivetrain is smooth shifting and reliable with a great range of gears to get you up or down any trail. To bring everything under control there is all-weather potent Shimano MT500 hydraulic disc brakes. The Dune has a mixture of Mondraker and OnOff components for the finishing kit with an OnOff Pija internally routed dropper post also included.
The traction comes from Maxxis with the superb Minion DHF at the front and the equally impressive Minion DHR II at the rear giving you tyres that can take a beating on the trails and provide excellent grip and stability.
The Dune is a highly capable bike that can be ridden as hard and fast as you dare downhill whilst being nimble enough to take you up any climb.
Frame:Dune 27.5" Stealth Zero Suspension System FG 170mm
Fork:RockShox Yari RC DebonAir Boost 170mm
Rear Shock:Fox Float DPX2 LV EVOL 3Pos Lever Performance 205x65mm Trunnion
Headset:OnOff Saturn Tapered ACB
Stem:OnOff Stoic FG 30mm
Bars:Mondraker Custom Design 1.0 780mm
Front Brake:Shimano MT501 203mmR
ear Brake:Shimano MT501 180mm
Brake Lever:Shimano MT501
Rear Mech:SRAM NX Eagle X-Hoizon Type3 12sS
hifters:SRAM NX Eagle Trigger Right 12s
Speed:12Rims:MDK EP1 27.5" TLR Asys27
Front Hub:MDK Pro II 15x110mm
Rear Hub:MDK Pro II 12x148mm
Spokes:CN Stainless
Front Tyre:Maxxis Minion DHF 27.5x2.5" EXO/TR
Rear Tyre:Minion DHR 27.5x2.4" EXO/TR
Seat Post:OnOff Dropper Pija Internal 1x Lever
Chainset:SRAM NX1 Boost DM 32T
Bottom Bracket:SRAM GXP XRChain:SRAM PC110
Cassette:Sunrace CSMS8 11-46T
